Terex TA9 - Hydraulic Circuit

Specifications
TA9 & TA10 Dumper 0803-4 July 2011 10-10
Hydraulic Circuit
1 Engine
2 Gearbox
3 hydraulic Pump 26.6 cc/rev
4 Transmission Oil Cooler
5 Services Oil Cooler
6 Relief Valve 200 bar (2900psi)
7 Control Valve Skip Raise/Lower
8 Rams - Skip
9 Steering Unit
10 Ram - Steering Unit
11 Filter
12 Hydraulic Oil Reservoir
