5-23 TA9 & TA10 Dumper 0803-2 November 2009
Description
b ROPS
A Roll Over Protective Structure (ROPS) is fitted to protect the operator should the machine over turn. For more information on ROPS
see ‘Safety’ section of this manual
The ROPS Identification Plate (D) is located on the top of the
ROPS.
The ROPS comprises of two sections (A & B) and is pivoted at
seat level to allow the ROPs to be tipped backwards to reduce
the transportation height - not the working height. A gas strut
(C) is fitted to assist in raising the ROPS.
The ROPS is secured in the raised position by a locking pin (E)
and a linch pin.
b
Under No Circumstances Modify the ROPS in Any Way
b
Only Lower the ROPS when Transporting the Dumper on a
Lorry / Trailer etc.
Beware of trapping fingers etc. in ROPS pivot areas.
