b Gradients
Slopes - Diagram A
When ascending or descending a gradient, especially when the
skip is loaded, the skip MUST ALWAYS face the top of the
incline.
Gradients
Maximum Slope Gradient - Diagram B
Maximum Gradient X = 20% (11º, 1 in 5)
b
ALWAYS Reverse Down Inclines
)
pic-036
b
ONLY Fill Swing Skip with Free Flowing Materials
X
B
pic-035
