Specifications
TA9 & TA10 Dumper 0803-4 July 2011 10-2
Data - Engine, Alternator and Battery
Data - Dumper Speeds and Brakes
Data - Fluid Capacities - litres (pints)
Data - Load Capacities
Data - Wheels and Tyres
Model Engine kW (hp) @ rpm Alternator
Output
Amps
Battery Cold Start Amps
TA9
Perkins 1104D-44T 74.5(99) @ 2200 Belt Driven 65 900CCA 90 AH
TA10
Gearbox
Transfer
Box
1st Gear 2nd Gear 3rd Gear 4th Gear Reverse
Front
Brakes
Rear
Brakes
ITL PowerShuttle TG300
5.6 kph
(3.5 mph)
8.9 kph
(5.5 mph)
16.4 kph
(10.1 mph)
28.8 kph
(17.9 mph)
as
forward
Yes Yes
Engine
Sump
Gearbox
Transfer
Box
Axles (including Hubs)
Front Rear
Fuel Tank
Hydraulic
Tank
Brake
Reservoir
Coolant
10.00 (21.1) 13.00 (27.5) 0.45 (0.95) 9.7 (20.5) 9.7 (20.5) 67.00 (141.6) 50.00 (105.7) 1.20 (2.5) 20 (42.3)
Model Payload - kg Payload - lbs
Water Level - litres (yd.
3
) Struck Level - litres (yd.
3
) Heaped - litres (yd.
3
)
TA9 9000 19,800 2,070 (2.7) 3,965 (5.1) 4,615 (6.0)
TA10 10,000 22,000 2,450 (3.2) 4,140 (5.42) 5,053 (6.61)
Model Tyre Specification/Capacity
Tyre Pressures
Wheel Nut Torque
Front Rear
TA9
500/60 x 22.5 3.8 bar (55 psi) 2.2 bar (32 psi) 630 Nm
