Terex TA9 - Electric Circuits

Specifications
TA9 & TA10 Dumper 0803-4 July 2011 10-4
Electric Circuit
10000 - Electric Circuit, Key and Colour Codes
Item Description Cable Colour Codes
1 Warning Light - Transmission oil temperature
B Black
2 Warning Light - Transmission oil pressure
G Green
3 Switch - Transmission oil temperature
K Pink
4 Switch - Transmission oil pressure
LG Light Green
5 Audible warning
N Brown
6 Switch - Parking brake
O Orange
7 Warning Light - Engine coolant temperature
P Purple
8 Warning Light - Parking brake ‘ON’
R Red
9 Switch - Engine coolant
S Slate
10 Solenoid - Cold start
U Blue
11 Switch - Cold start
T Turquoise
12 Hourmeter
W White
13 Warning Light - Battery charge
Y Yellow
14 Warning Light - Engine oil pressure
15 Switch - Engine oil pressure
16 Solenoid - Engine fuel
17 Engine glow plug
18 Alternator
19 Starter
20 Solenoid - Starter
21 Switch - Engine key start
22 Circuit breakers
23 Battery - 12v
24 Battery isolator
8005-0833A
