Terex TA9 User Manual

10-1 TA9 & TA10 Dumper 0803-4 July 2011
Specifications
Dimensions
Dimensions and Specification
Dimensions =
mm (ins)
A B C D E F G
H
ROPs Beacon
I
across
tyres
J
across
skip
Weight
(wet)
kg (lbs)
TA9
2,670
(105.1)
1,722
(67.8)
420
(16.5)
2,450
(96.5)
4,330
(170.5)
338
(13.3)
2,532
(99.7)
3,282
(129.2)
3,537
(139.3)
2,380
(93.7)
2,500
(98.4)
4,875
(10747)
TA10
2,695
(106.1)
1,760
(69.3)
440
(17.3)
2,450
(96.5)
4,450
(174)
338
(13.3)
2,630
(103.5)
3.375
(132.9)
3,630
(142.9)
2,380
(93.7)
2,550
(100.4)
4,920
(10847)
)
*
+
-
)
,
0
/
.
p0515-002

Terex TA9 Specifications
