Terrasat IBUC - Table 7-6 User Interface Connector J1, Pin Assignments; Table 7-7 Power Connectors J2 and J3, Pin Assignments

IBUC Operation Manual
Terrasat Communications, Inc.
Rev. A
7-18
Table 7.6 User Interface Connector J1, Pin Assignments
Rx 1+1 INTERFACE MODULE: J1
PI
N FUNCTION
A RS485 (+)
B RS485 (-)
C HANDHELD TERMINAL POWER (+)
D RS232 RXD
E RS232 TXD
F HHT, RS232 Common
G TCP/IP TX +
H TCP/IP TX -
J TCP/IP RX +
K TCP/IP RX -
L LNB-A ALARM OUTPUT Normally Open
M LNB-A ALARM OUTPUT Common
N LNB-A ALARM OUTPUT Normally Closed
P LNB-B ALARM OUTPUT Normally Open
R LNB-B ALARM OUTPUT Common
S LNB-B ALARM OUTPUT Normally Closed
T N/C
U
N/C
V
N/C
DC Power J2 and J3: Prime power is supplied to the Rx 1+1 Interface Module through
2-pin circular female connectors.
Table 7.7 Power Connectors J2 and J3, Pin Assignments
Rx 1+1 INTERFACE
MODULE: J2 and J3
PIN FUNCTION
A VDC COMMON
B VDC +
Receive In J4 and J5: The RX IN connectors are Type N, female connectors used to
connect the IF at L-band from the LNB’s to the Rx 1+1 Interface Module. 50Ω cables
are supplied with the Rx 1+1. The Rx 1+1 Interface Module supplies the LNB’s the
10MHz reference and VDC through these connectors.
Receive Out J6: The RX OUT connector is a Type N, female connector used to
connect the IF at L-band to the Modem. 50Ω cables should be used to connect to J6.
The Modem supplies through this connector the 10MHz reference signal for the LNB’s.
