Terrasat IBUC - Table 4-4 PSUI Connector Schedule; Table 4-5 PSUI AC Power Connector J1 Pin Assignments; Table 4-6 PSUI DC Output Connector J2, Pin Assignments

IBUC Operation Manual
Terrasat Communications Inc.
Rev. A
4-9
Table 4.4: PSUI Connector Schedule
PSUI CONNECTOR SCHEDULE
REF DESIG
FUNCTION
CONNECTOR CONNECTOR MATE
J1 AC IN
POWER CONNECTOR, MALE
RCPT, 3+PE (AMPHENOL T3110-
000)
POWER CONNECTOR,FEMALE,
3+PE (AMPHENOL T3109-001)
J2 DC OUT
MS CIRCULAR CONNECTOR BOX
MOUNT RCPT, 6S
(CAN MS3102R 14S-6S)
MS CIRCULAR CONNECTOR
STRAIGHT PLUG, 6P
(CAN MS3106F 14S-6P)
FAN CONN DC TO FAN
MICRO CONNECTOR, PANEL
MOUNT, 2-PIN (CONXALL 17282-
2PG-300)
MICRO CONNECTOR, CABLE
END, SOCKET (CONXALL 16282-
2SG-311)
Power Supply Connections
AC IN (J1): Prime power, AC, is provided via the circular, 3 –pin plus ground
connector. The connector is configured as follows
Table 4.5: PSUI AC Power Connector J1, Pin Assignments
PSUI J1
PIN FUNCTION
1 N/C
2 NEUTRAL
3 LINE
GRND GROUND
DC OUT (J2): DC out connector is used to provide power from the PSUI to the IBUC
using a 6-pin circular connector. Pin out for this connector is as follows:
Table 4.6: PSUI DC Output Connector J2, Pin Assignments
PSUI J2
PIN FUNCTION
A VDC -
B VDC-
C VDC-
D VDC+
E VDC+
F VDC+
The fan connection is a two-pin connector with a dust cover attached used to supply
power to a cooling fan when installed. Units without a fan or from which the fan is
removed should have the dust cover placed over the connector.
