Terrasat IBUC - Installation and Setup

IBUC Operation Manual
Terrasat Communications, Inc.
Rev. A
7-8
Rx Redundancy – It monitors not only the Voltage and current to the LNB, but also the
L-band composite input level, improving the fault detection.
Embedded Webpage – provides management for small networks using a web browser.
Alarm History – a log of all alarms that occur is maintained. This simplifies
troubleshooting of the system especially if an intermittent problem occurs.
Installation & Setup
The Terrasat ODU consists of a Tx 1+1 Redundant System, and could include an Rx
1+1 Redundant System, Redundant Power Supplies and a set of interconnection
cables. The Terrasat IDU consists of a hot-swappable dual Power Supply (indoor rack-
mount).
This section contains the general requirements for installation of the ODU to the
antenna and the IDU.
WARNING:
- FOR PROTECTION OF PERSONNEL AND EQUIPMENT, USE CARE
WHEN INSTALLING THE ANTENNA AND WHENEVER WORKING ON
OR AROUND THE SYSTEM.
- TAKE STANDARD SAFETY PRECAUTIONS WITH HAND AND/OR
POWER TOOLS.
- USE CARE IN WORKING WITH DANGEROUS VOLTAGES.
Unpacking
Check to make sure that the ODU has not suffered damage in shipment. If damage is
noticed contact Terrasat customer support.
Compare the contents of the shipping container with the packing list to ensure all items
have been received. If any item is determined to be missing contact Terrasat customer
support.
Retain all shipping containers for future use.
