IBUC Operation Manual 6-8
Terrasat Communications, Inc.
Rev. A
0x04 Detected carrier frequency LSB LSB
0x05 Power threshold LSB LSB
5 Data Byte 3 Factory Use Only 0xAA
6 Not used
7 Checksum Algebraic Sum of bytes 1-6 Sum of bytes
1-6
*Notes:
Command 0x05
For CSM mode the setting must be at 20.1 dB below rated power. For burst
mode the setting must be between rated power and no lower than 20 dB below
rated power.
Command 0x03, Data Byte 2
The smallest delay is 0x01, which is 1ms. The delay value of 0x00 is equal to
0xFF and gives a 256ms delay. The delay value of 0xAA is the only exception; it
will not change anything. It is aimed to keep compatibility with previous versions
of the software. It should be noted, that the time delay may not be accurate when
the EEPROM write command is being executed (delay time longer by few ms).
Response Message Structure
Refer to the Data Field Definitions at the end of this chapter for valid settings.
Table 6-4 Response to BUC commands 0x01, 0x02, 0x03, 0x04, and 0x08
Byte Name Description Value
1 Address Reports BUC Address shifted left by 4 bits 0x10 to 0xF0
2 Level Byte 1 Reports current TX output power MSB MSB
3 Level Byte 2 Reports current TX output power LSB LSB
4 Temperature Reports Housing Temperature in ºC
5 Status Byte 1
Bit 0: Housing Temperature 1=Out of
Range
0=Normal
Bit 1: PLDRO lock 1=Out of
Lock
0=Normal
Bit 2: Checksum 1=
Command
Error
0= Normal
Bit 3: TX status 1=On, 0=Off
Bits 4 to 7: Power class 0x1 to 0xA
6 Status Byte 2
Bits 0 to 3: Summary Alarm = On 0x9
Summary Alarm = Off 0xA
Bits 4 to 7: Software version 0x0 to 0xF
7 Checksum Algebraic Sum of bytes 1-6 Sum of bytes
