Terrasat IBUC - Handheld Terminal

IBUC Operation Manual 6-4
Terrasat Communications, Inc.
Rev. A
Handheld Terminal
Main Menu
4:CFG ALMS
Configure Alarms
5:MISC
Miscellaneous
0:INFO
TX Information
5:TX MODE
3:TX STARTUP
Startup Settings
2:FREQ
TX Frequency
Settings
0:REVERT
Revert Mode
1:CLONE
Clone Mode
0:ODU CFG
ODU Configuration
1:ODU INFO
ODU Information
3:SYS STAT
System Status
2:SENSORS
Sensor Information
0:LOGS
Alarm History Log
1:TX
TX Alarms
3:TEMP LOG
Temp Log
2:MISC
Misc. Alarms
2:SW Position
0: Read Logs
1: Clear Logs
0: Freq
1: Freq Band
2: Spect Inv
0: Startup Delay
4:BURST
Burst Mode
Settings
0: CSM/Burst Pwr Mode
1: TX Startup State
0:SYS
System Settings
1:TX
Transmit Settings
2:RED
Redundancy
Settings
3:INFO
System Information
4:ALM
Alarms
9:EXIT
Logout
3:RESET
Reset Settings
0: Change Password
1: Chg PW Timeout
2:PASSWD
Password Settings
0:NETWORK
Network Settings
0: IP Addr
1: Netmask
2: Ext IBUC IP addr
3: Gateway
4:TCP Port
1:SERIAL
Serial Port Settings
0:Set RS485 Address
1:Set Baud Rate
2: Legacy cmd mode
1:THRESHOLD
Alm Threshold
Settings
0: In Hi Th
1: In Lo Th
2: Out Hi Th
3: Out Lo Th
1:Burst Thr
2:Brst Ct
0:AGC/ALC Mode
0:O/L
1:ALC
2:AGC
3:Reset GC
1:TX Atten Setting
2:Show Gains
3:TX En
Reboot the machine?
4:ALM SIM
Alarm Simulate
5:ALM SUP
Alarm Suppress
Enter “. . . .“
Enter Password
0: No
1: Mnr
2: Maj
3: Togl Suprs
3:SW MODE
4:BUC Position
Scroll up/dn for:
TX Output lvl hi
TX Output lvl lo
TX Input lvl lo
TX Input lvl hi
Temperature Alarm
0:Hi temp shutdown
1:Ext LED enable
0: CSM
1: Burst
(Yes/No)
Figure 6.2 Hand Held Terminal Menu Tree
3) The FSK multiplexed onto the IF cable by means of an FSK modulated signal. FSK
operation allows two modes: Legacy-binary and ASCII. FSK-capable modems may
require that the IBUC operate in the legacy mode. Commands and values available
