Terrasat IBUC - Table 6-10 Alarm Flags; Embedded Web Pages

IBUC Operation Manual 6-28
Terrasat Communications, Inc.
Rev. A
Table 6.10: Alarm flags
Transmit
flags
0x0001 AGC or ALC out of range
0x0002 AGC or ALC not settled
0x0004 BUC loss-of-lock
0x0008 Tx Output Level Hi alarm
0x0010 Tx Output Level Low alarm
0x0020 Tx Input Level Hi alarm
0x0040 Tx Input Level Low alarm
0x0080 Temperature Alarm
0x0100 Tx Simulated fault
0x0200 10 MHz Reference Alarm
0x0400 VDC Out Of Range
0x0800 Waveguide Switch Fault
0x1000 Not Used
0x2000 IDC Out of Range alarm
0x4000 AGC/ALC Target Out of Range
0x8000 Not Used
Misc
flags
0x0001 Error-log pointers corrupted
0x0002 Fault in restoring config data
0x0004 Ethernet Download Alarm
0x0008 Serial Download Alarm
0x0010 Reboot Alarm
0x0020 Clone Communications Error
0x0040 Clone Read Fault
0x0080 Clone Write Fault
6) M&C using TCP/IP is displayed in embedded web pages. The user connects to the
IBUC M&C and enters the IBUC IP address through a web browser. This will bring
up a login page. After login, the operator has a choice of six web pages with
monitoring, control and alarm information. Below you’ll find a snapshot of the Login
page and all other six pages:
