Terumo CDI 550 - Choosing a monitor configuration

setting up the hardwarechapter 3 3-53-4
After the completion of the system diagnostics and the module self-tests, the printer
prints a heading like the following:
Terumo
®
CVS CDI
®
550
Blood Parameter Monitoring System
Date: 09/25/2018
Time: 13:00:49
Serial Number: 1001
Patient ID:
Monitor diagnostics: PASS
Arterial SRS check: PASS
Venous SRS check: PASS
H/S check PASS
Last calibration values in use
Note: The printout will note any monitor diagnostics failures.
Choosing a monitor conguration
After the system diagnostics and module self-tests have been completed, the monitor
conguration screen appears. On this screen, you specify the conguration of your
system — that is, which modules you want to use.
Note: If any of the modules failed their SRS or color chip checks, an error message
“REFERENCE SENSOR TEST FAILURE” appears in the message bar. The “A” , “V” ,
and/or “H/S” module indicators will ash indicating the failed modules.
1 Press the and keys to move the highlight to the configuration you want.
Note: The dimmed congurations indicate the required hardware is not available on
your system for that particular conguration. Therefore the dimmed congurations
cannot be selected.
Note: The starting choice will be the last one used.
2 Press the √ key when the desired configuration is highlighted.
If a blood parameter module (BPM) or a CDI H/S Probe has failed its self-test, you will
see a message that gives you two options:
 Cancel. If you choose this option, you’re prompted to re-select your monitor
conguration.
 Retry. If you choose this option, the module self-test repeats.
