9.3 Error messages and further displaying
Message Explanation
ERROR 0 Inclinometer is defective and must be sent for repair.
ERROR 1 Second inclinometer for differential measurement is not or badly
connected.
ERROR 2 « Sensor address » of a connected inclinometer still need be selected
(chapter 7.5).
ERROR 3 Reasons for this message to appear may either be the following:
- Correction values resulting from a calibration are missing (chapter 10).
- « ADDRESS / SENSOR » and « Port » indicate the faulty sensor.
- Power supply is not sufficient probably due to low batteries.
ERROR 4 No sensor address could be found.
ERROR 5 Several sensors are connected
ERROR 6 Address alteration failed.
ERROR 7 HOLD procedure could not be executed within 60 seconds and need
be repeated.
ERROR 8 Batteries are not properly inserted.
ERROR 9 Correction values obtained from a calibration could not be registered
(chapter 10).
Further displaying Explanation
Automatic configuration to the active functions
or the functions that were selected just before
switching your inclinometer off. This operation
requires some time.
« OVER Range »
One of both values at the end of the given
measuring range is exceeded
Notes
If you cancel an error message by pushing on ENTER, the inclinometer works in sensor
mode.
