TESA CLINOBEVEL 2 - 2 OPERATING ELEMENTS AND FUNCTION KEYS; Key Functions Overview

5
2 operating eleMents
Cross vial
« ZERO/SELECT » key
To select any function
« ON/MODE » key
To switch ON (OFF)
To enable the
configuration mode
To set zero temporarily
in mode « REL ZERO »
« ENTER » key
To confirm any entry
« HOLD » key
To lock display
To capture a value for
ZERO-OFFSET
Cover plate of the
battery set
Connexion for a second
inclinometer in differen-
tial measurement
RS 232 output
Display field
+
-
+
-
« SEND/ESC » key
To trigger a data transfer
To release the HOLD
function
Cancel of a data function
Measuring faces
Measurement channel
Number of sensor
Measuring
faces
