UNIMASTER
8
It's recommended to use three extensions at the maximum.
8 MEASURING COMBINATIONS
Complete UNIMASTER Set
Range, mm Measuring combination with measu-
ring element (E) and extensions, mm
Measuring combination using supple-
mentary extension 1000 mm, mm
225 – 250 250 – 275 E
250 – 275 275 – 300 E + 25
275 – 300 300 – 325 E + 50
300 – 325 325 – 350 E + 75
325 – 350 350 – 375 E + 100
350 – 375 375 – 400 E + 125
375 – 400 400 – 425 E + 150
400 – 425 425 – 450 E + 150 + 25
425 – 450 450 – 475 E + 150 + 50
450 – 475 475 – 500 E + 150 + 75
475 – 500 500 – 525 E + 150 + 100
500 – 525 525 – 550 E + 150 + 125
525 – 550 550 – 575 E + 300
550 – 575 575 – 600 E + 300 + 25
575 – 600 600 – 625 E + 300 + 50
600 – 625 625 – 650 E + 300 + 75
625 – 650 650 – 675 E + 300 + 100
650 – 675 675 –700 E + 300 + 125
675 –700 700 – 725 E + 450
700 – 725 725 – 750 E + 450 + 25
725 – 750 750 – 775 E + 450 + 50
750 – 775 775 – 800 E + 450 + 75
775 – 800 800 – 825 E + 450 + 100
800 – 825 825 – 850 E + 450 + 125
825 – 850 850 – 875 E + 600
850 – 875 875 – 900 E + 600 + 25
875 – 900 900 – 925 E + 600 + 50
900 – 925 925 – 950 E + 600 + 75
925 – 950 950 – 975 E + 600 + 100
950 – 975 975 – 1000 E + 600 + 125
975 – 1000 1000 – 1025 E + 600 + 150
1000 – 1025 1025 – 1050 E + 600 + 150 + 25
1025 – 1050 1050 – 1075 E + 600 + 150 + 50
1050 – 1075 1075 – 1100 E + 600 + 150 + 75
1075 – 1100 1100 – 1125 E + 600 + 150 + 100
1100 – 1125 1125 – 1150 E + 600 + 150 + 125
1125 – 1150 1150 –1175 E + 600 + 300
1150 –1175 1175 – 1200 E + 600 + 300 + 25
1175 – 1200 1200 – 1225 E + 600 + 300 + 50
1200 – 1225 1225 – 1250 E + 600 + 300 + 75
1225 – 1250 1250 – 1275 E + 600 + 300 + 100 E + 1000
1250 – 1275 1275 – 1300 E + 600 + 300 + 125 E + 1000 + 25
1275 – 1300 1300 – 1325 E + 600 + 450 E + 1000 + 50
1300 – 1325 1325 – 1350 E + 600 + 450 + 25 E + 1000 + 75
1325 – 1350 1350 –1375 E + 600 + 450 + 50 E + 1000 + 100
1350 –1375 1375 – 1400 E + 600 + 450 + 75 E + 1000 + 125
1375 – 1400 1400 –1425 E + 600 + 450 + 100 E + 1000 + 150
1400 –1425 1425 –1450 E + 600 + 450 + 125 E + 1000 + 150 + 25
1425 –1450 1450 – 1475 E + 600 + 450 + 150 E + 1000 + 150 + 50
