Settings view
Active menu
Function fields for entering commands
Scroll bar
Selection field for adjustable values:
The chosen value is shown with a grey
background. Unavailable values are written in grey
type.
Function keys for entering commands
Measuring view
Active menu, depending on the chosen function:
Additional information (e.g. activated fuel,
date and time)
Scroll bar
Display field for readings, parameters
Function keys for entering commands
C.1.4 Device connections
Probe socket
Flue gas socket
Mains unit socket
Pressure socket
C. Product description
C.1 Measuring instrument
11
