I.5 Cleaning the modular flue gas probe
Disconnect the flue gas probe from the measuring
instrument prior to cleaning.
1
Release the probe catch by pressing the key on
the probe handle and remove the probe module.
2
Blow compressed air through the flue ducts of the
probe module and probe handle (see illustration).
Do not use a brush!
3
Fit a new probe module on the handle and engage
it in place.
I.6 Changing the thermocouple
1
Release the probe catch by pressing the key on
the probe handle and remove the probe module.
2
Remove the thermocouple plug-in head from the
socket using a screwdriver and pull the
thermocouple out of the probe shaft.
3
Keep inserting new thermocouple in the probe
shaft until the connection head clicks into place.
4
Fit a new probe module on the handle and engage
it in place.
