F. Configuration
This chapter describes the possible steps for adapting the product to the particular
measurement task or the requirements of the user.
Familiarity with the contents of the chapter
Operation
(see p. 16)
is assumed.
F.1 Instrument settings
F.1.1 Display edit
The parameters/units and the display representation (number of readings displayed per
display page) can be set.
Available parameters and units:
Display Parameter Units
T1 Temperature 1 (flue gas socket) °C, °F
T2 Temperature 2 (probe socket) °C, °F
∆∆
T Differential temperature T1-T2 °C, °F
Itemp Instrument temperature °C, °F
DP Flue gas dew point temperature °C, °F
∆∆
P Differential pressure mbar, hPa,
mmW, inW
Gasfl Gas flow rate m
3
/h, l/h
GasP Gas burner output kW
OilFl Oil flow rate kg/h
Oil p Oil pressure bar
OilP Oil burner output kW
CO2 Carbon dioxide %
amCO2 Ambient carbon dioxide ppm
amCO Ambient carbon monoxide ppm
Pabs Absolute pressure hPa, mbar
Pump Pump output l/m
Display Parameter Units
FT Flue gas temperature °C, °F
CO2 Carbon dioxide %
qA Flue gas loss %
λλ
Air ratio -
O2 Oxygen %
CO Carbon monoxide ppm, %,
mgm
3
,
g/GJ,
mgKW
uCO Carbon monoxide undiluted ppm
ηη
Efficiency %
NO Nitrogen monoxide ppm, %,
mgm
3
,
g/GJ,
mgKW
NOx Nitrogen oxide ppm, %,
mgm3,
g/GJ,
mgKW
AT Ambient temperature °C, °F
O2 air Oxygen addition %
Drght Flue draught mbar, hPa,
mmWS,
inW
F. Configuration
F.1 Instrument settings
27
