TESTO 330-1 - Measurement Functions; Flue Gas Measurement

G.2 Measurements
G.2.1 Flue gas
The Flue gas menu is the main measuring menu in which - in addition to the readings
measured with this function - the readings of all measurements carried out are displayed
(if selected in the
Display edit menu). All readings can also be saved or printed out from
this menu.
The
Flue gas menu can always be selected, regardless of which probes are connected.
Calling up the function:

Measurements Flue gas  .
- Possibly: Gas zeroing (30 s).
If nno ffuel hhas yyet bbeen sselected:
Select the fuel  .
Measuring:
1
Start measuring: .
Reading CCO uundiluted:
If a separate measurement of CO undiluted has not yet been carried out, this value is
calculated using the readings of the flue gas probe and is updated continuously.
If CO undiluted has already been measured separately, the value obtained is adopt-
ed.
- The readings are displayed.
2
Stop measuring: .
Options:
To print readings: .
To save readings: .
- The readings from the flue gas measurement, as well as any readings taken over
into the menu
Flue Gas from other measurement functions are stored and/or print-
ed in a measurement protocol (automatic furnace data are not printed).
Save
Print
Stop
Start
OK
OKOK
G. Measuring
G.2 Measurements
35
