AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
www.ti.com
SPRS717H –OCTOBER 2011–REVISED MAY 2015
USB
USB/USB0 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
USB0_CE USB0 Active high Charger Enable output A T18 M15
USB0_DM USB0 Data minus A U18 N18
USB0_DP USB0 Data plus A U19 N17
USB0_DRVVBUS USB0 Active high VBUS control output O G16 F16
USB0_ID USB0 OTG ID (Micro-A or Micro-B Plug) A V19 P16
USB0_VBUS USB0 VBUS A T19 P15
USB/USB1 Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
USB1_CE USB1 Active high Charger Enable output A NA P18
USB1_DM USB1 Data minus A NA R18
USB1_DP USB1 Data plus A NA R17
USB1_DRVVBUS USB1 Active high VBUS control output O NA F15
USB1_ID USB1 OTG ID (Micro-A or Micro-B Plug) A NA P17
USB1_VBUS USB1 VBUS A NA T18
