AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
SPRS717H –OCTOBER 2011–REVISED MAY 2015
www.ti.com
(1) SIGNAL NAME: The signal name
(2) DESCRIPTION: Description of the signal
(3) TYPE: Ball type for this specific function:
– I = Input
– O = Output
– I/O = Input/Output
– D = Open drain
– DS = Differential
– A = Analog
(4) BALL: Package ball location
ADC Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
AIN0 Analog Input/Output A B8 B6
AIN1 Analog Input/Output A A11 C7
AIN2 Analog Input/Output A A8 B7
AIN3 Analog Input/Output A B11 A7
AIN4 Analog Input/Output A C8 C8
AIN5 Analog Input A B12 B8
AIN6 Analog Input A A10 A8
AIN7 Analog Input A A12 C9
VREFN Analog Negative Reference Input AP B9 A9
VREFP Analog Positive Reference Input AP A9 B9
Debug Subsystem Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
EMU0 MISC EMULATION PIN I/O A15 C14
EMU1 MISC EMULATION PIN I/O D14 B14
EMU2 MISC EMULATION PIN I/O A18, C15 A15, A17, C13
EMU3 MISC EMULATION PIN I/O B15, B18 B17, D13, D14
EMU4 MISC EMULATION PIN I/O B16, U17 A14, C15, T13
nTRST JTAG TEST RESET (ACTIVE LOW) I A13 B10
TCK JTAG TEST CLOCK I B14 A12
TDI JTAG TEST DATA INPUT I B13 B11
TDO JTAG TEST DATA OUTPUT O A14 A11
TMS JTAG TEST MODE SELECT I C14 C11
LCD Controller Signals Description
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
lcd_ac_bias_en LCD AC bias enable chip select O W7 R6
lcd_data0 LCD data bus I/O U1 R1
lcd_data1 LCD data bus I/O U2 R2
lcd_data10 LCD data bus I/O U5 U3
lcd_data11 LCD data bus I/O V5 U4
lcd_data12 LCD data bus I/O V6 V2
lcd_data13 LCD data bus I/O U6 V3
lcd_data14 LCD data bus I/O W6 V4
lcd_data15 LCD data bus I/O V7 T5
lcd_data16 LCD data bus O V17 U13
lcd_data17 LCD data bus O W17 V13
52 Terminal Configuration and Functions Copyright © 2011–2015, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Links: AM3359 AM3358 AM3357 AM3356 AM3354 AM3352
