LCD Controller Signals Description (continued)
TYPE
SIGNAL NAME [1] DESCRIPTION [2] ZCE BALL [4] ZCZ BALL [4]
[3]
lcd_data18 LCD data bus O T13 R12
lcd_data19 LCD data bus O U13 T12
lcd_data2 LCD data bus I/O V1 R3
lcd_data20 LCD data bus O U12 U12
lcd_data21 LCD data bus O T12 T11
lcd_data22 LCD data bus O W16 T10
lcd_data23 LCD data bus O V15 U10
lcd_data3 LCD data bus I/O V2 R4
lcd_data4 LCD data bus I/O W2 T1
lcd_data5 LCD data bus I/O W3 T2
lcd_data6 LCD data bus I/O V3 T3
lcd_data7 LCD data bus I/O U3 T4
lcd_data8 LCD data bus I/O V4 U1
lcd_data9 LCD data bus I/O W4 U2
lcd_hsync LCD Horizontal Sync O T7 R5
lcd_memory_clk LCD MCLK O L19, V16 J17, V12
lcd_pclk LCD pixel clock O W5 V5
lcd_vsync LCD Vertical Sync O U7 U5
