DC Electrical Characteristics
(1)
(continued)
over recommended ranges of supply voltage and operating temperature (unless otherwise noted)
PARAMETER MIN NOM MAX UNIT
RTC_PWRONRSTn
0.65 ×
V
IH
High-level input voltage V
VDDS_RTC
0.35 ×
V
IL
Low-level input voltage V
VDDS_RTC
V
HYS
Hysteresis voltage at an input 0.065 V
I
I
Input leakage current –1 1 µA
PMIC_POWER_EN
V
OH
High-level output voltage, driver enabled, pullup or I
OH
= 6 mA VDDS_RTC – V
pulldown disabled 0.45
V
OL
Low-level output voltage, driver enabled, pullup or I
OL
= 6 mA 0.45 V
pulldown disabled
I
I
Input leakage current, Receiver disabled, pullup or pulldown inhibited –1 1 µA
Input leakage current, Receiver disabled, pullup enabled –200 –40
Input leakage current, Receiver disabled, pulldown enabled 40 200
I
OZ
Total leakage current through the terminal connection of a driver-receiver –1 1 µA
combination that may include a pullup or pulldown. The driver output is
disabled and the pullup or pulldown is inhibited.
EXT_WAKEUP
0.65 ×
V
IH
High-level input voltage V
VDDS_RTC
0.35 ×
V
IL
Low-level input voltage V
VDDS_RTC
V
HYS
Hysteresis voltage at an input 0.15 V
I
I
Input leakage current, Receiver disabled, pullup or pulldown inhibited –1 1 µA
Input leakage current, Receiver disabled, pullup enabled –200 –40
Input leakage current, Receiver disabled, pulldown enabled 40 200
XTALIN (OSC0)
0.65 ×
V
IH
High-level input voltage V
VDDS_OSC
0.35 ×
V
IL
Low-level input voltage V
VDDS_OSC
RTC_XTALIN (OSC1)
0.65 ×
V
IH
High-level input voltage V
VDDS_RTC
0.35 ×
V
IL
Low-level input voltage V
VDDS_RTC
All other LVCMOS pins (VDDSHVx = 1.8 V; x = 1 to 6)
V
IH
High-level input voltage 0.65 × VDDSHVx V
V
IL
Low-level input voltage 0.35 × VDDSHVx V
V
HYS
Hysteresis voltage at an input 0.18 0.305 V
V
OH
High-level output voltage, driver enabled, pullup or I
OH
= 6 mA VDDSHVx – 0.45 V
pulldown disabled
V
OL
Low-level output voltage, driver enabled, pullup or I
OL
= 6 mA 0.45 V
pulldown disabled
Input leakage current, Receiver disabled, pullup or pulldown inhibited 8
I
I
Input leakage current, Receiver disabled, pullup enabled –161 –100 –52 µA
Input leakage current, Receiver disabled, pulldown enabled 52 100 170
I
OZ
Total leakage current through the terminal connection of a driver-receiver 8 µA
combination that may include a pullup or pulldown. The driver output is
disabled and the pullup or pulldown is inhibited.
All other LVCMOS pins (VDDSHVx = 3.3 V; x = 1 to 6)
V
IH
High-level input voltage 2 V
V
IL
Low-level input voltage 0.8 V
V
HYS
Hysteresis voltage at an input 0.265 0.44 V
