AM3359, AM3358, AM3357, AM3356, AM3354, AM3352
SPRS717H –OCTOBER 2011–REVISED MAY 2015
www.ti.com
DC Electrical Characteristics
(1)
(continued)
over recommended ranges of supply voltage and operating temperature (unless otherwise noted)
PARAMETER MIN NOM MAX UNIT
V
OH
High-level output voltage, driver enabled, pullup or I
OH
= 6 mA VDDSHVx – 0.45 V
pulldown disabled
V
OL
Low-level output voltage, driver enabled, pullup or I
OL
= 6 mA 0.45 V
pulldown disabled
Input leakage current, Receiver disabled, pullup or pulldown inhibited 18
I
I
Input leakage current, Receiver disabled, pullup enabled –243 –100 –19 µA
Input leakage current, Receiver disabled, pulldown enabled 51 110 210
I
OZ
Total leakage current through the terminal connection of a driver-receiver 18 µA
combination that may include a pullup or pulldown. The driver output is
disabled and the pullup or pulldown is inhibited.
