Texas Instruments AM5728 - PRU1 ETH0 RJ45 Connector - J3; PRU1 ETH1 RJ45 Connector - J5

Board Connectors www.ti.com
28
SPRUI97D–May 2017–Revised September 2019
Submit Documentation Feedback
Copyright © 2017–2019, Texas Instruments Incorporated
AM571x Industrial Development Kit (IDK) Evaluation Module (EVM)
Hardware
Table 11. PRU1ETH0 RJ45 Connector - J3
Pin Pin Name Signal Name
1 RD+ PRU1ETHER0_RDP
2 RD- PRU1ETHER0_RDN
3 RCT V3_3D
4 TCT V3_3D
5 TD+ PRU1ETHER0_TDP
6 TD- PRU1ETHER0_TDN
7 N/C No connect
8 AC GND DGND
9 YEL LED Anode V3_3D
10 YEL LED Cathode RXLINK
11 GRN LED Anode V3_3D
12 GRN LED Cathode PRU1ETH0_LINKLED
SHLD1 Shield AGNDFRAME_PRU1ETH0
SHLD2 Shield AGNDFRAME_PRU1ETH0
Table 12. PRU1ETH1 RJ45 Connector - J5
Pin Pin Name Signal Name
1 RD+ PRU1ETHER1_RDP
2 RD- PRU1ETHER1_RDN
3 RCT V3_3D
4 TCT V3_3D
5 TD+ PRU1ETHER1_TDP
6 TD- PRU1ETHER1_TDN
7 N/C No connect
8 AC GND DGND
9 YEL LED Anode V3_3D
10 YEL LED Cathode RXLINK
11 GRN LED Anode V3_3D
12 GRN LED Cathode PRU1ETH1_LINKLED
SHLD1 Shield AGNDFRAME_PRU1ETH1
SHLD2 Shield AGNDFRAME_PRU1ETH1
