Board Connectors
www.ti.com
34
SPRUI97D–May 2017–Revised September 2019
Submit Documentation Feedback
Copyright © 2017–2019, Texas Instruments Incorporated
AM571x Industrial Development Kit (IDK) Evaluation Module (EVM)
Hardware
Table 24. JTAG USB Micro-AB Connector - J19
Pin Pin Name Signal Name
1 VBUS VUSB_JTAG
2 DM EMU_USB_DM
3 DP EMU_USB_DP
4 ID No Connect
5 GND DGND
S1 S1 GNDUSBJ
S2 S2 GNDUSBJ
S3 S3 GNDUSBJ
S4 S4 GNDUSBJ
Table 25. USB Port 1 USB2.1 Standard A-type Connector - J23
Pin Pin Name Signal Name
1 VBUS VUSB_VBUS1
2 DM USB1_CONN_DM
3 DP USB1_CONN_DP
4 GND DGND
S1 S1 GNDUSB1
S2 S2 GNDUSB1
Table 26. USB Port 2 USB2.1 Micro-AB Connector - J45
Pin Pin Name Signal Name
1 VBUS VUSB_VBUS2
2 DM USB2_CONN_DM
3 DP USB2_CONN_DP
4 ID USB2_ID
5 GND DGND
S1 S1 GNDUSB2
S2 S2 GNDUSB2
S3 S3 GNDUSB2
S4 S4 GNDUSB2
