www.ti.com
Board Connectors
27
SPRUI97D–May 2017–Revised September 2019
Submit Documentation Feedback
Copyright © 2017–2019, Texas Instruments Incorporated
AM571x Industrial Development Kit (IDK) Evaluation Module (EVM)
Hardware
Table 8. MicroSD Connector - J15
Pin Pin Name Signal Name
1 DAT2 MMC_D2
2 DAT3 MMC_D3
3 CMD MMC_CMD
4 VDD V3_3D
5 CLOCK MMC_CLK
6 DGND VSS
7 DAT0 MMC_D0
8 DAT1 MMC_D1
9 GND DGND
10 CD MMC1_SDCD
11 GND3 DGND
12 GND4 DGND
13 GND5 DGND
14 GND6 DGND
15 GND7 DGND
16 GND8 DGND
Table 9. Power Jack Connector - J1
Pin Signal Name
1 VPWRIN_JCK
2 DGND
3 DGND
Table 10. Power Terminal Block Connector - J2
Pin Signal Name
1 VPWRIN_JCK
2 DGND
