Board Connectors www.ti.com
26
SPRUI97D–May 2017–Revised September 2019
Submit Documentation Feedback
Copyright © 2017–2019, Texas Instruments Incorporated
AM571x Industrial Development Kit (IDK) Evaluation Module (EVM)
Hardware
Table 7. I/O Expansion Header Connector - J37
Pin Signal Name
1 INDUS_INPUT0
2 V12_0D
3 INDUS_INPUT1
4 V12_0D
5 INDUS_INPUT2
6 V12_0D
7 INDUS_INPUT3
8 V12_0D
9 INDUS_INPUT4
10 V12_0D
11 INDUS_INPUT5
12 V12_0D
13 INDUS_INPUT6
14 V12_0D
15 INDUS_INPUT7
16 V12_0D
17 DGND
18 No Connect
19 DRAIN0
20 DRAIN1
21 DRAIN2
22 DRAIN3
23 DRAIN4
24 DRAIN5
25 DRAIN6
26 DRAIN7
27 V5_0D
28 V5_0D
29 DGND
30 DGND
