AM571x Industrial Development Kit (IDK) Evaluation Module (EVM)
Hardware
Table 13. PRU2ETH0 RJ45 Connector - J6
Pin Pin Name Signal Name
1 RD+ PRU2ETHER0_RDP
2 RD- PRU2ETHER0_RDN
3 RCT V3_3D
4 TCT V3_3D
5 TD+ PRU2ETHER0_TDP
6 TD- PRU2ETHER0_TDN
7 N/C No connect
8 AC GND DGND
9 YEL LED Anode V3_3D
10 YEL LED Cathode RXLINK
11 GRN LED Anode V3_3D
12 GRN LED Cathode PRU2ETH0_LINKLED
SHLD1 Shield AGNDFRAME_PRU2ETH0
SHLD2 Shield AGNDFRAME_PRU2ETH0
Table 14. PRU2ETH1 RJ45 Connector - J8
Pin Pin Name Signal Name
1 RD+ PRU2ETHER1_RDP
2 RD- PRU2ETHER1_RDN
3 RCT V3_3D
4 TCT V3_3D
5 TD+ PRU2ETHER1_TDP
6 TD- PRU2ETHER1_TDN
7 N/C No connect
8 AC GND DGND
9 YEL LED Anode V3_3D
10 YEL LED Cathode RXLINK
11 GRN LED Anode V3_3D
12 GRN LED Cathode PRU2ETH1_LINKLED
SHLD1 Shield AGNDFRAME_PRU2ETH1
SHLD2 Shield AGNDFRAME_PRU2ETH1
