Board Connectors
33
SPRUI97D–May 2017–Revised September 2019
Submit Documentation Feedback
Copyright © 2017–2019, Texas Instruments Incorporated
AM571x Industrial Development Kit (IDK) Evaluation Module (EVM)
Hardware
Table 22. HDMI Standard A-type Connector - J24
Pin Pin Name Signal Name
1 DAT2+ HDMI_TX2+
2 DAT2_S DGND
3 DAT2- HDMI_TX2-
4 DAT1+ HDMI_TX1+
5 DAT1_S DGND
6 DAT1- HDMI_TX1-
7 DAT0+ HDMI_TX0+
8 DAT0_S DGND
9 DAT0- HDMI_TX0-
10 CLK+ HDMI_CLK+
11 CLK_S DGND
12 CLK- HDMI_CLK-
13 CEC HDMICONN_CEC
14 N/C No Connect
15 SCL HDMICONN_I2CSCL
16 SDA HDMICONN_I2CSDA
17 DDC/CEC GND DGND
18 +5V V5_0HDMICONN
19 HPLG HDMICONN_HPLG
MTG1 Shield DGND
MTG2 Shield DGND
MTG3 Shield DGND
MTG4 Shield DGND
Table 23. CTI-20 JTAG Connector - J18
Pin Pin Name Signal Name
1 TMS JTAG_TMS
2 TRSTn JTAG_TRSTn
3 TDI JTAG_TDI
4 TDIS PD to GND
5 TVDD PU to V3_3D
6 PU to V3_3D —
7 TDO JTAG_TDO
8 DGND —
9 TCKRTN RTCK
10 DGND EMU_DET
11 TCK JTAG_TCK
12 DGND —
13 EMU0 JTAG_EMU0
14 EMU1 JTAG_EMU1
15 SRST EMU_RSTn
16 DGND —
17 EMU2 No Connect
18 EMU3 No Connect
19 EMU4 No Connect
20 DGND —
