www.ti.com
Board Connectors
31
SPRUI97D–May 2017–Revised September 2019
Submit Documentation Feedback
Copyright © 2017–2019, Texas Instruments Incorporated
AM571x Industrial Development Kit (IDK) Evaluation Module (EVM)
Hardware
Table 18. GigE RJ45 Connector - J10
Pin Pin Name Signal Name
1 CH-GND DGND
2 VCC No connect
3 MX3+ ETHER0_D3P
4 MX3- ETHER0_D3N
5 MX2+ ETHER0_D2P
6 MX2- ETHER0_D2N
7 MX1+ ETHER0_D1P
8 MX1- ETHER0_D1N
9 MX0+ ETHER0_D0P
10 MX0- ETHER0_D0N
11 RT GRN Anode PU to PHY0_LED_ACTn
12 RT YEL Anode DGND
13 LEFT GRN Anode DGND
14 LEFT YEL Anode PU to PHY0_LED_LINKn
SHLD1 Shield AGND_GBETH0
SHLD2 Shield AGND_GBETH0
Table 19. GigE RJ45 Connector - J12
Pin Pin Name Signal Name
1 CH-GND DGND
2 VCC No connect
3 MX3+ ETHER1_D3P
4 MX3- ETHER1_D3N
5 MX2+ ETHER1_D2P
6 MX2- ETHER1_D2N
7 MX1+ ETHER1_D1P
8 MX1- ETHER1_D1N
9 MX0+ ETHER1_D0P
10 MX0- ETHER1_D0N
11 RT GRN Anode PU to PHY1_LED_ACTn
12 RT YEL Anode DGND
13 LEFT GRN Anode DGND
14 LEFT YEL Anode PU to PHY1_LED_LINKn
SHLD1 Shield AGND_GBETH1
SHLD2 Shield AGND_GBETH1
