Board Connectors
www.ti.com
32
SPRUI97D–May 2017–Revised September 2019
Submit Documentation Feedback
Copyright © 2017–2019, Texas Instruments Incorporated
AM571x Industrial Development Kit (IDK) Evaluation Module (EVM)
Hardware
Table 20. LCD Module FFC Connector - J16
Pin Pin Name Signal Name
1 — No Connect
2 — No Connect
3 VCC V3_7LCD
4 VCC V3_7LCD
5 VCC V3_7LCD
6 — No Connect
7 GND DGND
8 MIPI_LN3_N LCD_MIPI3N
9 MIPI_LN3_P LCD_MIPI3P
10 GND DGND
11 MIPI_LN2_N LCD_MIPI2N
12 MIPI_LN2_P LCD_MIPI2P
13 GND DGND
14 MIPI_LN1_N LCD_MIPI1N
15 MIPI_LN1_P LCD_MIPI1P
16 GND DGND
17 MIPI_LN0_N LCD_MIPI0N
18 MIPI_LN0_P LCD_MIPI0P
19 GND DGND
20 MIPI_CLK_N LCD_CLKN
21 MIPI_CLK_P LCD_CLKP
22 GND DGND
23 LED_CATHODE VLED-
24 LED_CATHODE VLED-
25 LED_CATHODE VLED-
26 LED_CATHODE VLED-
27 LED_CATHODE VLED-
28 LED_CATHODE VLED-
29 LED Anode Supply VLED+
30 LED Anode Supply VLED+
31 — No Connect
32 — No Connect
Table 21. Touchscreen Controller FFC Connector - J17
Pin Pin Name Signal Name
1 SDA IND_I2C_SDA
2 SCL IND_I2C_SCL
3 TSC_RESETn GPIO_TOUCH_RESETn
4 TSC_INT TOUCH_INT
5 V+ V3_3D
6 GND DGND
