AM571x Industrial Development Kit (IDK) Evaluation Module (EVM)
Hardware
Table 27. CAN Header Connector - J38
Pin Signal Name
1 VCAN1
2 CAN1_H
3 CAN1_L
4 GND_CAN1
5 No Connect
Table 28. Profibus DB9F Connector - J14
Pin Signal Name
1 No Connect
2 No Connect
3 PROFIBUS_A
4 No Connect
5 GND_PROFI
6 VPROFI
7 No Connect
8 PROFIBUS_B
9 No Connect
Table 29. RS-485 Header Connector - J39
Pin Signal Name
1 RS485_A
2 RS485_B
3 DGND
