AM571x Industrial Development Kit (IDK) Evaluation Module (EVM)
Hardware
Table 6. Expansion Connector - J21 (continued)
Pin Signal Name Secondary Signal Name
45 PR1_MII0_RXDV —
46 AM57XX_GPMC_AD14 AM57XX_PR1_UART0_TXD
47 PR1_MII0_RXD3 —
48 AM57XX_GPMC_AD15 AM571X_VIN2A_D2
49 AM57XX_PR2_PROFI_TXEN —
50 HDQ AM571X_RGMII0_RXCLK
51 AM57XX_GPMC_AD4 PR1_MII0_RXD2
52 GPMC_WAIT0 —
53 AM57XX_GPMC_AD5 PR1_MII0_RXD1
54 AM571X_PRU1ETH1_TXD1 AM57XX_PRU2ETH0_CRS
55 AM57XX_GPMC_AD6 PR1_MII0_RXD0
56 AM571X_PRU1ETH1_TXD0 AM57XX_PRU2ETH0_COL
57 AM57XX_GPMC_AD7 —
58 GPMC_CLK —
59 DGND —
60 DGND —
