MSP430F5529
,
MSP430F5528
,
MSP430F5527
,
MSP430F5526
MSP430F5525
,
MSP430F5524
,
MSP430F5522
,
MSP430F5521
MSP430F5519, MSP430F5517, MSP430F5515, MSP430F5514, MSP430F5513
www.ti.com
SLAS590M –MARCH 2009–REVISED NOVEMBER 2015
7 Device and Documentation Support
7.1 Device Support
7.1.1 Getting Started and Next Steps
For an introduction to the MSP430™ family of devices and the tools and libraries that are available to help
with your development, visit the Getting Started page.
7.1.2 Development Tools Support
All MSP microcontrollers are supported by a wide variety of software and hardware development tools.
Tools are available from TI and various third parties. See them all at MSP Tools.
7.1.2.1 Hardware Features
See the Code Composer Studio for MSP430 User's Guide (SLAU157) for details on the available features.
BREAK- RANGE LPMx.5
MSP430 4-WIRE 2-WIRE CLOCK STATE TRACE
POINTS BREAK- DEBUGGING
ARCHITECTURE JTAG JTAG CONTROL SEQUENCER BUFFER
(N) POINTS SUPPORT
MSP430Xv2 Yes Yes 8 Yes Yes Yes Yes No
7.1.2.2 Recommended Hardware Options
7.1.2.2.1 Target Socket Boards
The target socket boards allow easy programming and debugging of the device using JTAG. They also
feature header pin outs for prototyping. Target socket boards are orderable individually or as a kit with the
JTAG programmer and debugger included. The following table shows the compatible target boards and
the supported packages.
PACKAGE TARGET BOARD AND PROGRAMMER BUNDLE TARGET BOARD ONLY
64-pin VQFN (RGC) MSP-FET430U64USB MSP-TS430RGC64USB
80-pin LQFP (PN) MSP-FET430U80USB MSP-TS430PN80USB
7.1.2.2.2 Experimenter Boards
Experimenter Boards and Evaluation kits are available for some MSP devices. These kits feature
additional hardware components and connectivity for full system evaluation and prototyping. See MSP
Tools for details.
7.1.2.2.3 Debugging and Programming Tools
Hardware programming and debugging tools are available from TI and from its third party suppliers. See
the full list of available tools at MSP Tools.
7.1.2.2.4 Production Programmers
The production programmers expedite loading firmware to devices by programming several devices
simultaneously.
PART NUMBER PC PORT FEATURES PROVIDER
Program up to eight devices at a time. Works with PC or as a stand-
MSP-GANG Serial and USB Texas Instruments
alone package.
Copyright © 2009–2015, Texas Instruments Incorporated Device and Documentation Support 109
Submit Documentation Feedback
Product Folder Links: MSP430F5529 MSP430F5528 MSP430F5527 MSP430F5526 MSP430F5525 MSP430F5524
MSP430F5522 MSP430F5521 MSP430F5519 MSP430F5517 MSP430F5515 MSP430F5514 MSP430F5513
