MSP430F5529
,
MSP430F5528
,
MSP430F5527
,
MSP430F5526
MSP430F5525
,
MSP430F5524
,
MSP430F5522
,
MSP430F5521
MSP430F5519, MSP430F5517, MSP430F5515, MSP430F5514, MSP430F5513
SLAS590M –MARCH 2009–REVISED NOVEMBER 2015
www.ti.com
2 Revision History
NOTE: Page numbers for previous revisions may differ from page numbers in the current version.
Changes from Revision L (June 2013) to Revision M Page
• Formatting and organization changes throughout, including addition of section numbering ............................... 1
• Added Device Information table .................................................................................................... 2
• Added Section 1.4 and moved all functional block diagrams to it.............................................................. 3
• Added Section 3 and moved Family Members table to it ....................................................................... 7
• Added Section 5 and moved all electrical specifications to it ................................................................. 19
• Added Section 5.2, ESD Ratings.................................................................................................. 19
• Moved Section 5.6, Thermal Characteristics .................................................................................... 23
• Changed the TYP value of C
L,eff
with Test Conditions of "XTS = 0, XCAPx = 0" from 2 pF to 1 pF..................... 28
• Corrected MRG0 and MRG1 bit names in f
MCLK,MRG
parameter description................................................. 49
• Corrected spelling of NMIIFG in Table 6-9, System Module Interrupt Vector Registers................................... 60
• Corrected register names (added "USB" prefix as necessary) in Table 6-45, USB Control Registers .................. 80
• Changed P5.3 schematic (added P5SEL.2 and XT2BYPASS inputs, AND gate, and OR gate after P5SEL.3) ....... 89
• Changed P5SEL.3 column from X to 0 for "P5.3 (I/O)" rows.................................................................. 89
• Changed P5.5 schematic (change input from P5SEL.5 to P5SEL.4 and added P5SEL.5 input and the following
OR gate).............................................................................................................................. 91
• Changed P5SEL.5 column from X to 0 for "P5.5 (I/O)" rows.................................................................. 91
• Added Section 7 and moved Tools Support, Device Nomenclature, ESD Caution, and Trademarks sections to it.. 109
• Added Section 8, Mechanical, Packaging, and Orderable Information..................................................... 114
6 Revision History Copyright © 2009–2015, Texas Instruments Incorporated
Submit Documentation Feedback
Product Folder Links: MSP430F5529 MSP430F5528 MSP430F5527 MSP430F5526 MSP430F5525 MSP430F5524
MSP430F5522 MSP430F5521 MSP430F5519 MSP430F5517 MSP430F5515 MSP430F5514 MSP430F5513
