MSP430F5529
,
MSP430F5528
,
MSP430F5527
,
MSP430F5526
MSP430F5525
,
MSP430F5524
,
MSP430F5522
,
MSP430F5521
MSP430F5519, MSP430F5517, MSP430F5515, MSP430F5514, MSP430F5513
www.ti.com
SLAS590M MARCH 2009REVISED NOVEMBER 2015
5.4 Active Mode Supply Current Into V
CC
Excluding External Current
over recommended operating free-air temperature (unless otherwise noted)
(1) (2) (3)
FREQUENCY (f
DCO
= f
MCLK
= f
SMCLK
)
EXECUTION
PARAMETER V
CC
PMMCOREVx 1 MHz 8 MHz 12 MHz 20 MHz 25 MHz UNIT
MEMORY
TYP MAX TYP MAX TYP MAX TYP MAX TYP MAX
0 0.36 0.47 2.32 2.60
1 0.40 2.65 4.0 4.4
I
AM, Flash
Flash 3.0 V mA
2 0.44 2.90 4.3 7.1 7.7
3 0.46 3.10 4.6 7.6 10.1 11.0
0 0.20 0.24 1.20 1.30
1 0.22 1.35 2.0 2.2
I
AM, RAM
RAM 3.0 V mA
2 0.24 1.50 2.2 3.7 4.2
3 0.26 1.60 2.4 3.9 5.3 6.2
(1) All inputs are tied to 0 V or to V
CC
. Outputs do not source or sink any current.
(2) The currents are characterized with a Micro Crystal MS1V-T1K crystal with a load capacitance of 12.5 pF. The internal and external load
capacitance are chosen to closely match the required 12.5 pF.
(3) Characterized with program executing typical data processing. USB disabled (VUSBEN = 0, SLDOEN = 0).
f
ACLK
= 32786 Hz, f
DCO
= f
MCLK
= f
SMCLK
at specified frequency.
XTS = CPUOFF = SCG0 = SCG1 = OSCOFF= SMCLKOFF = 0.
Copyright © 2009–2015, Texas Instruments Incorporated Specifications 21
Submit Documentation Feedback
Product Folder Links: MSP430F5529 MSP430F5528 MSP430F5527 MSP430F5526 MSP430F5525 MSP430F5524
MSP430F5522 MSP430F5521 MSP430F5519 MSP430F5517 MSP430F5515 MSP430F5514 MSP430F5513
