Page #47 background imageLoading...
Page #47 background image
MSP430F5529
,
MSP430F5528
,
MSP430F5527
,
MSP430F5526
MSP430F5525
,
MSP430F5524
,
MSP430F5522
,
MSP430F5521
MSP430F5519, MSP430F5517, MSP430F5515, MSP430F5514, MSP430F5513
www.ti.com
SLAS590M MARCH 2009REVISED NOVEMBER 2015
5.44 USB Output Ports DP and DM
over recommended ranges of supply voltage and operating free-air temperature (unless otherwise noted)
PARAMETER TEST CONDITIONS MIN MAX UNIT
V
OH
D+, D– single ended USB 2.0 load conditions 2.8 3.6 V
V
OL
D+, D– single ended USB 2.0 load conditions 0 0.3 V
Z(DRV) D+, D– impedance Including external series resistor of 27 Ω 28 44 Ω
Full speed, differential, C
L
= 50 pF,
t
RISE
Rise time 4 20 ns
10%/90%, Rpu on D+
Full speed, differential, C
L
= 50 pF,
t
FALL
Fall time 4 20 ns
10%/90%, Rpu on D+
5.45 USB Input Ports DP and DM
over recommended ranges of supply voltage and operating free-air temperature (unless otherwise noted)
PARAMETER MIN MAX UNIT
V
(CM)
Differential input common mode range 0.8 2.5 V
Z
(IN)
Input impedance 300 kΩ
V
CRS
Crossover voltage 1.3 2.0 V
V
IL
Static SE input logic low level 0.8 V
V
IH
Static SE input logic high level 2.0 V
VDI Differential input voltage 0.2 V
Copyright © 2009–2015, Texas Instruments Incorporated Specifications 47
Submit Documentation Feedback
Product Folder Links: MSP430F5529 MSP430F5528 MSP430F5527 MSP430F5526 MSP430F5525 MSP430F5524
MSP430F5522 MSP430F5521 MSP430F5519 MSP430F5517 MSP430F5515 MSP430F5514 MSP430F5513
