RM46L852
SPNS185 –SEPTEMBER 2012 www.ti.com
2.3.1.4 Enhanced Quadrature Encoder Pulse Modules (eQEP)
Table 2-4. PGE Enhanced Quadrature Encoder Pulse Modules (eQEP)
(1)
Terminal Signal Default Pull Type Description
Type Pull State
Signal Name 144
PGE
MIBSPI3CLK/AWM1_EXT_SEL[1]/EQEP1A 53 Input Pull Up Fixed, 20uA Enhanced QEP1 Input A
MIBSPI3NENA/MIBSPI3NCS[5]/N2HET1[31]/EQEP1B 54 Input Enhanced QEP1 Input B
MIBSPI3NCS[0]/AD2EVT/GIOB[2]/EQEP1I/N2HET2_PIN_nDI 55 I/O Enhanced QEP1 Index
S
MIBSPI1NCS[1]/N2HET1[17]/MII_COL 130 I/O Enhanced QEP1 Strobe
/USB1.SUSPEND /EQEP1S
N2HET1[01]/SPI4NENA/USB2.TXEN/ 23 Input Pull Down Enhanced QEP2 Input A
USB_FUNC.PUENO/N2HET2[8]/EQEP2A
N2HET1[03]/SPI4NCS[0]/USB2.SPEED/ 24 Input Enhanced QEP2 Input B
USB_FUNC.PUENON/N2HET2[10]/EQEP2B
GIOA[2]/USB2.TXDAT/USB_FUNC.TXDO/N2HET2[0]/EQEP 9 I/O Enhanced QEP2 Index
2I
N2HET1[30]/MII_RX_DV/USB1.SPEED/EQEP2S 127 I/O Enhanced QEP2 Strobe
(1) These signals are double-synchronized and then optionally filtered with a 6-cycle VCLK4-based counter.
