RM46L852
SPNS185 –SEPTEMBER 2012
www.ti.com
2.3.1.6 General-Purpose Input / Output (GIO)
Table 2-6. PGE General-Purpose Input / Output (GIO)
Terminal Signal Default Pull Type Description
Type Pull State
Signal Name 144
PGE
GIOA[0]/USB2.VP/USB_FUNC.RXDPI 2 I/O Pull Down Programmable, General-purpose I/O.
20uA All GIO terminals are
GIOA[1]/USB2.VM/USB_FUNC.RXDMI 5
capable of generating
GIOA[2]/USB2.TXDAT/USB_FUNC.TXDO/N2HET2[0]/EQEP 9
interrupts to the CPU on
2II
rising / falling / both
edges.
GIOA[5]/EXTCLKIN/EPWM1A/N2HET1_PIN_nDIS 14
GIOA[6]/N2HET2[4]/EPWM1B 16
GIOA[7]/N2HET2[6]/EPWM2A 22
GIOB[0]/USB1.TXDAT 126
GIOB[1]/USB1.PortPower 133
GIOB[2] 142
MIBSPI3NCS[0]/AD2EVT/GIOB[2]/EQEP1I/N2HET2_PIN_nD 55
(1)
Pull Up
IS
GIOB[3]USB2.RCV/USB_FUNC.RXDI 1 Pull Down
(1) GIOB[2] cannot output a level on to pin 55. Only the input functionality is supported so that the application can generate an interrupt
whenever the N2HET2_PIN_nDIS is asserted (driven low). Also, a pull up is enabled on the input. This is not programmable using the
GIO module control registers.
2.3.1.7 Controller Area Network Controllers (DCAN)
Table 2-7. PGE Controller Area Network Controllers (DCAN)
Terminal Signal Default Pull Type Description
Type Pull State
Signal Name 144
PGE
CAN1RX 90 I/O Pull Up Programmable, CAN1 receive, or GIO
20uA
CAN1TX 89 CAN1 transmit, or GIO
CAN2RX 129 CAN2 receive, or GIO
CAN2TX 128 CAN2 transmit, or GIO
CAN3RX 12 CAN3 receive, or GIO
CAN3TX 13 CAN3 transmit, or GIO
2.3.1.8 Local Interconnect Network Interface Module (LIN)
Table 2-8. PGE Local Interconnect Network Interface Module (LIN)
Terminal Signal Default Pull Type Description
Type Pull State
Signal Name 144
PGE
LINRX 131 I/O Pull Up Programmable, LIN receive, or GIO
20uA
LINTX 132 LIN transmit, or GIO
16 Device Package and Terminal Functions Copyright © 2012, Texas Instruments Incorporated
