RM46L852
SPNS185 –SEPTEMBER 2012
www.ti.com
2.3.1.12 Multi-Buffered Serial Peripheral Interface Modules (MibSPI)
Table 2-12. PGE Multi-Buffered Serial Peripheral Interface Modules (MibSPI)
Terminal Signal Default Pull Type Description
Type Pull State
Signal Name 144
PGE
MIBSPI1CLK 95 I/O Pull Up Programmable, MibSPI1 clock, or GIO
20uA
MIBSPI1NCS[0]/MIBSPI1SOMI[1]/MII_TXD[2]/ 105 MibSPI1 chip select, or
USB1.RCV/ECAP6 GIO
MIBSPI1NCS[1]/N2HET1[17]/MII_COL 130
/USB1.SUSPEND /EQEP1S
MIBSPI1NCS[2]/N2HET1[19]/MDIO 40
N2HET1[15]/MIBSPI1NCS[4]/ECAP1 41 Pull Down Programmable, MibSPI1 chip select, or
20uA GIO
N2HET1[24]/MIBSPI1NCS[5]/MII_RXD[0]/RMII_RXD[0] 91
MIBSPI1NENA/N2HET1[23]/MII_RXD[2]/ 96 Pull Up Programmable, MibSPI1 enable, or GIO
USB1.VP/ECAP4 20uA
MIBSPI1SIMO 93 MibSPI1 slave-in master-
out, or GIO
N2HET1[08]/MIBSPI1SIMO[1]/MII_TXD[3]/ 106 Pull Down Programmable, MibSPI1 slave-in master-
USB1.OverCurrent 20uA out, or GIO
MIBSPI1SOMI 94 Pull Up Programmable, MibSPI1 slave-out master-
20uA in, or GIO
MIBSPI1NCS[0]/MIBSPI1SOMI[1]/MII_TXD[2]/ 105
USB1.RCV/ECAP6
MIBSPI3CLK/AWM1_EXT_SEL[1]/EQEP1A 53 I/O Pull Up Programmable, MibSPI3 clock, or GIO
20uA
MIBSPI3NCS[0]/AD2EVT/GIOB[2]/EQEP1I/N2HET2_PIN_nD 55 MibSPI3 chip select, or
IS GIO
MIBSPI3NCS[1]/N2HET1[25]/MDCLK 37
MIBSPI3NCS[2]/I2C_SDA/N2HET1[27]/nTZ2 4
MIBSPI3NCS[3]/I2C_SCL/N2HET1[29]/nTZ1 3
N2HET1[11]/MIBSPI3NCS[4]/N2HET2[18]/ 6 Pull Down Programmable, MibSPI3 chip select, or
USB2.OverCurrent/USB_FUNC.VBUSI/EPWM1SYNCO 20uA GIO
MIBSPI3NENA /MIBSPI3NCS[5]/N2HET1[31]/EQEP1B 54 Pull Up Programmable, MibSPI3 chip select, or
20uA GIO
MIBSPI3NENA/MIBSPI3NCS[5]/N2HET1[31]/EQEP1B 54 MibSPI3 enable, or GIO
MIBSPI3SIMO/AWM1_EXT_SEL[0]/ECAP3 52 MibSPI3 slave-in master-
out, or GIO
MIBSPI3SOMI/AWM1_EXT_ENA/ECAP2 51 MibSPI3 slave-out master-
in, or GIO
MIBSPI5CLK/MII_TXEN/RMII_TXEN 100 I/O Pull Up Programmable, MibSPI5 clock, or GIO
20uA
MIBSPI5NCS[0]/EPWM4A 32 MibSPI5 chip select, or
GIO
MIBSPI5NENA/MII_RXD[3]/USB1.VM/MIBSPI5SOMI[1]/ECA 97 MibSPI5 enable, or GIO
P5
MIBSPI5SIMO[0]/MII_TXD[1]/RMII_TXD[1]/MIBSPI5SOMI[2] 99 MibSPI5 slave-in master-
out, or GIO
MIBSPI5SOMI[0]/MII_TXD[0]/RMII_TXD[0] 98 MibSPI5 slave-out master-
in, or GIO
MIBSPI5NENA/MII_RXD[3]/USB1.VM/MIBSPI5SOMI[1]/ECA 97 MibSPI5 SOMI, or GIO
P5
MIBSPI5SIMO[0]/MII_TXD[1]/RMII_TXD[1]/MIBSPI5SOMI[2] 99 MibSPI5 SOMI, or GIO
18 Device Package and Terminal Functions Copyright © 2012, Texas Instruments Incorporated
