RM46L852
www.ti.com SPNS185 –SEPTEMBER 2012
Table 2-17. PGE USB Device Port Controller Interface (USB_FUNC)
Terminal Signal Default Pull Type Description
Type Pull State
Signal Name 144
PGE
N2HET1[07]/USB2.PortPower/USB_FUNC.GZO/N2HET2[14] 33 Output Pull Down - Pull Up enable, allows for
software-programmable
USB device
connect/disconnect
N2HET1[01]/SPI4NENA/USB2.TXEN/USB_FUNC.PUENO/ 23 PUENO inverted
N2HET2[8]
N2HET1[03]/SPI4NCS[0]/USB2.SPEED/USB_FUNC.PUENO 24
N/
N2HET2[10]/EQEP2B
GIOB[3]/USB2.RCV/USB_FUNC.RXDI 1 Input Pull Down Fixed, 20uA USB device single-ended
data input
GIOA[1]/USB2.VM/USB_FUNC.RXDMI 5 USB device logic value of
D-minus
GIOA[0]/USB2.VP/USB_FUNC.RXDPI 2 USB device logic value of
D-plus
N2HET1[22]/USB2.TXSE0/USB_FUNC.SE0O 15 Output Pull Down - USB device single-ended
zero
N2HET1[09]/N2HET2[16]/USB2.SUSPEND/ 35 USB device suspend
USB_FUNC.SUSPENDO output
GIOA[2]/USB2.TXDAT/USB_FUNC.TXDO/N2HET2[0] 9 USB device transmit data
N2HET1[11]/MIBSPI3NCS[4]/N2HET2[18]/ 6 Input Pull Down Fixed, 20uA USB device power
USB2.OverCurrent/USB_FUNC.VBUSI/EPWM1SYNCO connected
2.3.1.15 System Module Interface
Table 2-18. PGE System Module Interface
Terminal Signal Default Pull Type Description
Type Pull State
Signal Name 144
PGE
nPORRST 46 Input Pull Down 100uA Power-on reset, cold reset
External power supply
monitor circuitry must
drive nPORRST low when
any of the supplies to the
microcontroller fall out of
thespecified range. This
terminal has a glitch filter.
See Section 4.8.
nRST 116 I/O Pull Up 100uA System reset, warm reset,
bidirectional.
The internal circuitry
indicates any reset
condition by driving nRST
low.
The external circuitry can
assert a system reset by
driving nRST low. To
ensure that an external
reset is not arbitrarily
generated, TI
recommends that an
external pull-up resistor is
connected to this terminal.
This terminal has a glitch
filter. See Section 4.8.
