RM46L852
SPNS185 –SEPTEMBER 2012
www.ti.com
2.3.2.2 Enhanced High-End Timer Modules (N2HET)
Table 2-26. ZWT Enhanced High-End Timer Modules (N2HET)
Terminal Signal Default Pull Type Description
Type Pull State
Signal Name 337
ZWT
N2HET1[0]/SPI4CLK/EPWM2B K18 I/O Pull Down Programmable,
N2HET1 time input
20uA
N2HET1[01]/SPI4NENA/N2HET2[8] V2
capture or output
compare, or GIO.
N2HET1[02]/SPI4SIMO/EPWM3A W5
Each terminal has a
N2HET1[03]/SPI4NCS[0]/USB2.SPEED/ U1
suppression filter that
USB_FUNC.PUENON/N2HET2[10]/EQEP2B
ignores input pulses
N2HET1[04]/EPWM4B B12
smaller than a
N2HET1[05]/SPI4SOMI/N2HET2[12]/EPWM3B V6 programmable duration.
N2HET1[06]/SCIRX/EPWM5A W3
N2HET1[07]/EPWM7B/USB2.PortPower/ T1
USB_FUNC.GZO/N2HET2[14]/EPWM7B
N2HET1[08]/MIBSPI1SIMO[1]/MII_TXD[3]/ E18
USB1.OverCurrent
N2HET1[09]/N2HET2[16]/ V7
USB2.SUSPEND/USB_FUNC.SUSPENDO/EPWM7A
N2HET1[10]/MII_TX_CLK/ D19
USB1.TXEN/MII_TX_AVCLK4/nTZ3
N2HET1[11]/MIBSPI3NCS[4]/N2HET2[18]/ E3
USB2.OverCurrent/USB_FUNC.VBUSI/EPWM1SYNCO
N2HET1[12]/MII_CRS/RMII_CRS_DV B4
N2HET1[13]/SCITX/EPWM5B N2
N2HET1[14]/USB1.TXSE0 A11
N2HET1[15]/MIBSPI1NCS[4]/ECAP1 N1
N2HET1[16]/EPWM1SYNCI/EPWM1SYNCO A4
N2HET1[17] A13
N2HET1[18]/EPWM6A J1
N2HET1[19] B13
N2HET1[20]/EPWM6B P2
N2HET1[21] H4
N2HET1[22]/USB2.TXSE0/USB_FUNC.SE0O B3
N2HET1[23] J4
N2HET1[24]/MIBSPI1NCS[5]/MII_RXD[0]/RMII_RXD[0] P1
N2HET1[25] M3
N2HET1[26]/MII_RXD[1]/RMII_RXD[1] A14
N2HET1[27] A9
N2HET1[28]/MII_RX_CLK/RMII_REFCLK/MII_RX_AVCLK4 K19
N2HET1[29] A3
N2HET1[30]/MII_RX_DV/USB1.SPEED/EQEP2S B11
N2HET1[31] J17
GIOA[5]/EXTCLKIN/EPWM1A/N2HET1_PIN_nDIS B5 input Pull Down Fixed, 20uA
26 Device Package and Terminal Functions Copyright © 2012, Texas Instruments Incorporated
