RM46L852
www.ti.com
SPNS185 –SEPTEMBER 2012
2.3.2.7 Controller Area Network Controllers (DCAN)
Table 2-31. ZWT Controller Area Network Controllers (DCAN)
Terminal Signal Default Pull Type Description
Type Pull State
Signal Name 337
ZWT
CAN1RX B10 I/O Pull Up Programmable, CAN1 receive, or GIO
20uA
CAN1TX A10 CAN1 transmit, or GIO
CAN2RX H1 CAN2 receive, or GIO
CAN2TX H2 CAN2 transmit, or GIO
CAN3RX M19 CAN3 receive, or GIO
CAN3TX M18 CAN3 transmit, or GIO
2.3.2.8 Local Interconnect Network Interface Module (LIN)
Table 2-32. ZWT Local Interconnect Network Interface Module (LIN)
Terminal Signal Default Pull Type Description
Type Pull State
Signal Name 337
ZWT
LINRX A7 I/O Pull Up Programmable, LIN receive, or GIO
20uA
LINTX B7 LIN transmit, or GIO
2.3.2.9 Standard Serial Communication Interface (SCI)
Table 2-33. ZWT Standard Serial Communication Interface (SCI)
Terminal Signal Default Pull Type Description
Type Pull State
Signal Name 337
ZWT
N2HET1[06]/SCIRX/EPWM5A W3 I/O Pull Down Programmable, SCI receive, or GIO
20uA
N2HET1[13]/SCITX/EPWM5B N2 SCI transmit, or GIO
Copyright © 2012, Texas Instruments Incorporated Device Package and Terminal Functions 31
