RM46L852
www.ti.com
SPNS185 –SEPTEMBER 2012
Table 2-47. No Connects (continued)
Terminal Signal Default Pull Type Description
Type Pull State
Signal Name 337
ZWT
NC T2 - - - No Connects. These balls
are not connected to any
NC T3 - - -
internal logic and can be
NC T4 - - -
connected to the PCB
ground without affecting
NC T5 - - -
the functionality of the
NC T6 - - -
device.
NC T7 - - -
NC T8 - - -
NC T9 - - -
NC T10 - - -
NC T11 - - -
NC T13 - - -
NC T14 - - -
NC U3 - - -
NC U4 - - -
NC U5 - - -
NC U6 - - -
NC U7 - - -
NC U8 - - -
NC U9 - - -
NC U10 - - -
NC U11 - - -
NC U12 - - -
NC V3 - - -
NC V4 - - -
NC V11 - - -
NC V12 - - -
NC W4 - - -
NC W13 - - -
2.3.2.21 Supply for Core Logic: 1.2V nominal
Table 2-48. ZWT Supply for Core Logic: 1.2V nominal
Terminal Signal Default Pull Type Description
Type Pull State
Signal Name 337
ZWT
VCC F9 1.2V - - Core supply
Power
VCC F10
VCC H10
VCC J14
VCC K6
VCC K8
VCC K12
VCC K14
VCC L6
VCC M10
VCC P10
Copyright © 2012, Texas Instruments Incorporated Device Package and Terminal Functions 43
