RM46L852
www.ti.com
SPNS185 –SEPTEMBER 2012
4.6.1.1.1 Timing Requirements for Main Oscillator
Table 4-9. Timing Requirements for Main Oscillator
Parameter MIN Type MAX Unit
tc(OSC) Cycle time, OSCIN (when using a sine-wave input) 50 200 ns
tc(OSC_SQR) Cycle time, OSCIN, (when input to the OSCIN is a 12.5 200 ns
square wave )
tw(OSCIL) Pulse duration, OSCIN low (when input to the OSCIN 15 ns
is a square wave)
tw(OSCIH) Pulse duration, OSCIN high (when input to the OSCIN 15 ns
is a square wave)
Copyright © 2012, Texas Instruments Incorporated System Information and Electrical Specifications 63
Submit Documentation Feedback
