CLKSRG
CLKG =
1+ CLKGDV
109
TMS320F28069
,
TMS320F28068
,
TMS320F28067
,
TMS320F28066
TMS320F28065, TMS320F28064, TMS320F28063, TMS320F28062
www.ti.com
SPRS698F NOVEMBER 2010REVISED MARCH 2016
Submit Documentation Feedback
Product Folder Links: TMS320F28069 TMS320F28068 TMS320F28067 TMS320F28066 TMS320F28065
TMS320F28064 TMS320F28063 TMS320F28062
Detailed DescriptionCopyright © 2010–2016, Texas Instruments Incorporated
6.9.6 Multichannel Buffered Serial Port (McBSP) Module
The McBSP module has the following features:
Compatible to McBSP in TMS320C28x/TMS320F28x DSP devices
Full-duplex communication
Double-buffered data registers that allow a continuous data stream
Independent framing and clocking for receive and transmit
External shift clock generation or an internal programmable frequency shift clock
A wide selection of data sizes including 8-, 12-, 16-, 20-, 24-, or 32-bits
8-bit data transfers with LSB or MSB first
Programmable polarity for both frame synchronization and data clocks
Highly programmable internal clock and frame generation
Direct interface to industry-standard CODECs, Analog Interface Chips (AICs), and other serially
connected analog-to-digital (A/D) and digital-to-analog (D/A) devices
Works with SPI-compatible devices
The following application interfaces can be supported on the McBSP:
T1/E1 framers
IOM-2 compliant devices
AC97-compliant devices (the necessary multiphase frame synchronization capability is provided.)
IIS-compliant devices
SPI
McBSP clock rate,
where CLKSRG source could be LSPCLK, CLKX, or CLKR. Serial port performance is limited by I/O
buffer switching speed. Internal prescalers must be adjusted such that the peripheral speed is less
than the I/O buffer speed limit.
NOTE
See Section 6.9 for maximum I/O pin toggling speed.
NOTE
On the 80-pin package, only the clock-stop mode (SPI) of the McBSP is supported.
