TMS320F28069
,
TMS320F28068
,
TMS320F28067
,
TMS320F28066
TMS320F28065, TMS320F28064, TMS320F28063, TMS320F28062
www.ti.com
SPRS698F NOVEMBER 2010REVISED MARCH 2016
Submit Documentation Feedback
Product Folder Links: TMS320F28069 TMS320F28068 TMS320F28067 TMS320F28066 TMS320F28065
TMS320F28064 TMS320F28063 TMS320F28062
Detailed DescriptionCopyright © 2010–2016, Texas Instruments Incorporated
6.9.8 Inter-Integrated Circuit (I
2
C)
The device contains one I
2
C Serial Port. Figure 6-47 shows how the I
2
C peripheral module interfaces
within the device.
The I
2
C module has the following features:
Compliance with the Philips Semiconductors I
2
C-bus specification (version 2.1):
Support for 1-bit to 8-bit format transfers
7-bit and 10-bit addressing modes
General call
START byte mode
Support for multiple master-transmitters and slave-receivers
Support for multiple slave-transmitters and master-receivers
Combined master transmit/receive and receive/transmit mode
Data transfer rate of from 10 kbps up to 400 kbps (I
2
C Fast-mode rate)
One 4-word receive FIFO and one 4-word transmit FIFO
One interrupt that can be used by the CPU. This interrupt can be generated as a result of one of the
following conditions:
Transmit-data ready
Receive-data ready
Register-access ready
No-acknowledgment received
Arbitration lost
Stop condition detected
Addressed as slave
An additional interrupt that can be used by the CPU when in FIFO mode
Module enable/disable capability
Free data format mode
