Teze TW-EOR48 - Icon Function Descriptions; Load Power and Battery SOC Indicators; System Status and Protection Indicators; Battery Type and Mode Indicators

Add: Building A, Xinlida Industrial Park, Junzibu Village,Guanlan Street, Longhua District ,Shenzhen,
Guangdong
TEL :0755-23225527 FAX:0755-23225537
23
Indicates load power
60%~79%
Indicates battery SOC 60%~79%
Indicates load power
40%~59%
Indicates battery SOC 40%~59%
Indicates load power
20%~39%
Indicates battery SOC 20%~39%
Indicates load power
5%~19%
Indicates battery SOC 5%~19%
Indicates battery under-
voltage
Indicates battery discharge
Indicates over-load
Indicates BMS fault
Indicates system
communication error
Indicates system under-voltage
Indicates system over-
voltage
Indicates system under-
temperature
Indicates battery is full
Indicates system over-current
Indicates sealed lead-acid
battery
Indicates user defined battery
Indicates gel lead-acid
battery
Indicates flooded lead-acid
battery
Indicates LFP li-ion battery
Indicates energy-saving mode
Indicates PV energy is
carrying the load
Indicates PV energy is charging
the battery
Indicates ACIN energy is
charging the battery
Indicates the inverter output
mode is mains power first
Indicates the inverter output
mode is bypass
Indicates the inverter output
mode is solar first
Indicates the inverter output
mode is battery first
